PHOTONICS TECHNOLOGIES IN THE LASER & LIGHT SOURCES INDUSTRY SECTOR

Looking for a light-based technology in the Laser & Light Sources industry? Choose PhotonTransfer as your comprehensive source for photonics technologies in the Laser & Light Sources worldwide market. Check out the latest opportunities and new technologies in the Laser & Light Sources industrial sector. If you're a user, source manufacturer or a system supplier there is something here for you.

Listings

83 listings found
Lightweight Adaptive Metal Cooled Mirror

LIGHTWEIGHT ADAPTIVE METAL COOLED MIRROR

Tech for Transfer

UAH_techsell

19-05-2015

Additive manufacturing is the process of printing a three-dimensional structure based on a solid CAD model. A major advantage of additive manufacturing is its ability to create 3D structures that would otherwise be extremely difficult to produce. However, the capabilities of additive manufacturing have not been explored in regards to heat mitigation in optical mirrors, such as those used in solar collection systems.

Lasers
Tell me more
Laser-assisted tape placement of thermoplastic composites

LASER-ASSISTED TAPE PLACEMENT OF THERMOPLASTIC COMPOSITES

Tech for Transfer

ANU__techsell

20-05-2015

Method for processing thermoplastic materials using a laser-assisted tape placement system.

Lasers
Tell me more
Efficient Cooling of LED Lamps

EFFICIENT COOLING OF LED LAMPS

Tech for Transfer

OG__techsell

28-05-2015

This invention presents an integrated lighting system that facilitates the cooling of LEDs by using a heatsink with an optimized structure that maximizes the heat removal by natural convection and thermal radiation. This cooling technique is the most efficient solution for solving the problem of hot spots formed in the chips of multiple LED systems and in the phosphor used for changing color in LEDs.

Light sources
Tell me more
Adaptive attenuating spatial light modulator

ADAPTIVE ATTENUATING SPATIAL LIGHT MODULATOR

Tech for Transfer

UOC__techsell

08-06-2015

It is often desirable to control the contrast of specific regions of an image in a variety of applications despite extreme variations in brightness of light emanating from neighboring regions. For example, intensified CCD cameras used for night vision suffer from blooming and halo, meaning that distant, bright sources of light look larger and closer than they are, because the excess charge on the CCD "spills over" into adja- cent areas. This results in distortion and/or masking of the portion of the image originating near the bright light source.

Adaptive Optics   Light sources
Tell me more
Axicon lens array with large depth-of-field and focusing range

AXICON LENS ARRAY WITH LARGE DEPTH-OF-FIELD AND FOCUSING RANGE

Tech for Transfer

TTO

16-12-2015

An optical lens array for imaging and illumination applications is provided. The lens array comprises three conical surface lenses or axicons positioned along the same optical axis. The third axicon provides an objective lens to a focal region and is positioned at a fixed location in the array. The distance between the first and second axicons can be altered to control the position of the focal region defined by the depth of field for imaging applications and depth of focus for illumination applications of the third axicon.

Optical Components & Devices
Tell me more
III-V photonic integration on silicon

III-V PHOTONIC INTEGRATION ON SILICON

Tech for Transfer

TTO

17-12-2015

Technology for making photonic integrated circuits on silicon by bonding a wafer of III-V material as an active region to silicon and removing the substrate. The coupling between the silicon waveguide and the III-V gain region allows for integration of low threshold lasers, tunable lasers, and other photonic integrated circuits with CMOS integrated circuits.

Optoelectronics   Semiconductors
Tell me more
Direct laser and ultraviolet lithography of porous silicon photonic crystal devices

DIRECT LASER AND ULTRAVIOLET LITHOGRAPHY OF POROUS SILICON PHOTONIC CRYSTAL DEVICES

Tech for Transfer

TTO

18-12-2015

A simple method to locally change the optical properties of porous silicon multilayers and photonic crystal architectures. This technique allows for the direct photolithography of porous silicon multilayers, heterostructures, and photonic crystals.

Adaptive Optics   Glass & other optical materials   Optical Components & Devices
Tell me more
Low-Temperature, High-Rate Nitride Alloy Growth Process

LOW-TEMPERATURE, HIGH-RATE NITRIDE ALLOY GROWTH PROCESS

Tech for Transfer

TTO

19-12-2015

Group-III Nitride semiconductor alloy growth process that works at lower temperatures while achieving higher growth rates than conventional processes. This method improves upon other processes by periodically modulating the metal flux while maintaining a constant nitrogen flux.

Semiconductors   Thin-Film Materials
Tell me more
High peak power optical amplifier

HIGH PEAK POWER OPTICAL AMPLIFIER

Tech for Transfer

TTO

19-12-2015

A method and apparatus for providing a high peak power optical beam. The method includes interleaving pulse trains of different wavelengths and spatially and temporally overlapping the different wavelengths to produce an amplified output beam with very high peak power.

Lasers   Optical Components & Devices
Tell me more
Thulium laser

THULIUM LASER

Tech for Transfer

TTO

19-12-2015

A laser with a gain medium comprising crystalline material (e.g., a polycrystalline material) doped with thulium and a method of generating light from a gain medium comprising crystalline material doped with thulium.

Lasers   Light sources   Optical Engineering
Tell me more
